Asha 302 Charging Problem Ways Solution

In today’s article I am posting the solution for Nokia Asha 302 Charging Problem. If you have damaged the phone’s charging connector prints I have marked their jumper points in the diagram below this article.

There is not a lot to explain here I have marked both Nokia Asha 302 Charging connector points. The Red jumper point directly connects to F2050 which is the Fuse replace it if you can or simply remove and bypass it as shown in the diagram. Next it connects to the 1st and second points of R2050, then it connects to C2050 and then it passes through L2050. If you have problem with L2050 don’t bypass it replace it with a new one. Finally it connects to C2051.

Black jumper point connects to the 3rd and 4th leg of R2050, and then it goes to the other sides of the C2050 & C2051.

Please Note that we will edit these solutions or add new ones if found in this page at any time in the future. So feel free to come back any time on this page to stay up to date.

Here Are Nokia Asha 302 Charging Problem Solutions. Please Observe Carefully.

Asha 302 Mic Problem Solution Ways

This acticle is for Nokia Asha 302 Mic Problem Solution. If your phone’s microphone has stopped working consult the digram in this article to solve this problem and have your Nokia Asha 302 Microphone working again.

After making sure that a faulty microphone is not causing this issue move on and make the jumpers as shown in this diagram. Nokia Asha 302 Mic’s 1st jumper point goes to R2116 the 2nd one is ground. The 3rd point goes to C2115 & R2117 at the same time and finally the 4th one goes to R2115.

Please Note that we will edit these solutions or add new ones if found in this page at any time in the future. So feel free to come back any time on this page to stay up to date.

Here Are Nokia Asha 302 Mic Ways Problem Solutions. Please Observe Carefully.

Asha 302 Battery Connector Ways Problem Solution

In this post I have marked Nokia Asha 302 Battery Connector ways jumpers points. If you have damaged Nokia Asha 302 Battery Connector prints make the jumpers as shown in the diagram below to solve your problem.

This solution is pretty self explanatory, the first leg of battery connector marked with Red Jumper is the positive connection of the battery. It is connected to C2082 and C2084. The second one is marked with Black is the Ground. Finally the third one marked with Orange Jumper is BSI point and is connected to C2083.

Please Note that we will edit these solutions or add new ones if found in this page at any time in the future. So feel free to come back any time on this page to stay up to date.

Here Are Nokia Asha 302 Battery Connector Ways Problem Solutions. Please Observe Carefully.

Asha 302 Power Button Ways Problem Solution

This solution is for Nokia Asha 302 Power Button Ways and Jumpers points. If your phone’s power button is not working you can use the guide in this article to solve your problem.

First of all check the phone if anything else is not causing this problem. If your phone is off and you can’t check the button plug the charger in and see if the phone is charging, if it isn’t turning and it isn’t charging too then probably the problem is with your phone’s software and you need to flash it. If the phone is on or charging but the power button is not working make the jumpers as shown in the diagram below. Nokia Asha 302 Power Button Middle Positive is connected to R2400.

Sorry about the schematics picture in between the regular picture of the motherboard but the only picture I had of Nokia Asha 302 motherboard had the cover in it. So I have took the schematics picture and pasted it on the main diagram. The jumper is marked with red point so you can get the clear idea where to make the connection.

Please Note that we will edit these solutions or add new ones if found in this page at any time in the future. So feel free to come back any time on this page to stay up to date.

Here Are Nokia Asha 302 Power Button Ways Problem Solutions. Please Observe Carefully.

Nokia Asha 302 Power Button Ways Jumpers

Asha 302 Lights Problem Ways Solution

This post is for Nokia Asha 302 Led Lights Problem Solution. If your phone’s LCD back lights are not working use the information in this article to solve this problem.

I have marked Nokia Asha 302 LCD Led Lights Jumper points from LCD connector. VLED+ is the 12th leg on LCD Connector it is connected to L2400, C2400, J2400 and finally connects to L2501 & C2501. VLED- is the 13th leg on Nokia Asha 302 LCD Connector and is connected to C2401, L2401 and finally J2401. Before doing these jumpers please make sure that a faulty LCD connector is not causing this issue.

Please Note that we will edit these solutions or add new ones if found in this page at any time in the future. So feel free to come back any time on this page to stay up to date.

Here Are Nokia Asha 302 Led Lights Ways Problem Solutions. Please Observe Carefully.

Nokia Asha 302 Led Lights Ways Jumpers

Asha 302 Camera Problem Ways Solution

Solution in this article is for Nokia Asha 302 Camera Problem. If your Nokia Asha 302 Camera is not working or you have a busted camera connector use the diagram in this article to solve this problem.

I have marked all the camera connector legs jumper points that I could find in this diagram. Please before doing any of these jumpers make sure that a faulty camera module is not causing this problem. The first leg marked with Red jumper is connected to C1483, second marked with Blue is connected to C1484 and C1485 at the same time. Third marked with Green goes to J1400 and 4th goes to J1401. 5th and 6th marked with Orange I could not trace sorry but the jumpers of the those legs are not available at the time. I will keep it in my checklist though as soon as I am able to trace them I will update the diagram or post a new diagram here.

Moving on to the other side of the camera connector of Nokia Asha 302 the 7th leg marked with black as you might have already judged is ground. Leg No. 8,9,11 & 12 go the jumpers points on the front of the motherboard right between Navigation Down and Power Button. 8th is connected to J1480, 9th is connected to J1482, 11th is connected to J1484 & 12th is connected to J1486. Now the final the 10th leg is connected to C1487 and C1486 at the same time which are placed right next to the 10th leg of the Nokia Asha 302 Camera Connector. That about covers all the camera connector jumpers points I could find. I hope this will be helpful to you.

Please Note that we will edit these solutions or add new ones if found in this page at any time in the future. So feel free to come back any time on this page to stay up to date.

Here Are Nokia Asha 302 Camera Connector Ways Problem Solutions. Please Observe Carefully.

Nokia Asha 302 Camera Connector Ways Jumpers

If you have further Questions please don’t hesitate to leave a comment.

gfive w5 charging solution

This solution help you for gfive w5 phone charging problem.If you face this problem then first check your charger if any confusion of your charger then you try other charger.If problem still then open the phone and check red mark parts and check green line ways.

Tips of gfive w5 charging repair

1.When you connect your phone with charger If you see no response on your phone then check green line ways.

2. If charging show on mobile phone but charge not save or not store then you check inside red mark parts and replace damage parts.Maximum time this problem solve replacing charging ic.

Gfive w5 ear speaker solution

Ear speaker very important  of voice call.When damage ear speaker or speaker ways then ear speaker not work.there are this solution following below picture.

First check ear speaker if damage ear speaker change speaker.If ear speaker ok but problem stiill. Next check ear speaker ways, if you see broken ear speaker ways make this jumper.

Gfive w5 mic solution

Now i share repair of gfive w5 mic problem.In the first check mic or replace mic.Next check mic ways.this shown to the below picture.

This is main line of gfive w5 mic ways.If you change a new mic but problem still then replace a good microphone.

Gfive W5 network solution

Network solution of gfive w5 phone,If any body face this problem view the below picture.There are shown how to repair this solution.

How to do this work : At first restore factory setting using security code 1234 and open your phone see result.If result same then check ant of your phone.next check ant line and next rehot pa.But problem still then change pa.

Gfive w5 ringer solution

Gfive w5 is very loud sound phone.so may be ringer problem in any time.there  are shown how to repair ringer porblem.check speaker next check ringer ways.

Then check ringer ic and related parts.if you see damage any parts replace that.

Gfive w5 pinout

This is gfive w5 pinout one of them RX another is TX

This RX TX help you for flashing this phone .

Nokia 1616 network ic jumper

May be many reason of Nokia 1616 network problem.Pa damage is one of them.When damage pa then have  no network on this phone or network stay some seconds.If you have this problem of your phone then you can apply this solution.

How to do this work: If you face this problem then first check your sim card.Because some time are network problem for sim card.If problem still then rplace pa of other same phone.If you have no pa on your hand then you can apply this jumper.

Mobile phones first aid for fall into water

Your phone may be fall into water.If you face this situation what to do  then.Now I showing what to do then.

1. At first remove battery then
2. Remove sim card and memory card  next
3. Remove water with cloth or tissue then
4. Take dry to sun temperature If do not possible dry to sun temperature then you can dry to electronic bulb.
5. When you understand there are no water in your phone then put battery and on your phone.If your phone not on then check your phone  with other battery.
6. If your phone not on then go to nearest service center and repair your phone.

Symphony t44 Mic solution

This is symphony t44 mic problem solution.It also work  symphony t44 mic line ways.mic not work and mic low voice solution.



How to do this : If your phone has this problem then first change microphone next check mic line ways,If damage mic line then make this jumper.

Symphony d25 mic solution

This is symphony d25 mic solution.Microphone problem is very common problem.Its repair very easy Now I showing how to repair it.this solution also work mic low voice problem.

How to do this solution : Check or change microphone next check mic line ways if line are not ok then make this jumper.

symphony t44 no service solution

This solution help you Symphony t44 no service problem repairing.No service is a network problem.when damage any parts of network part.but maximum time when damage PA then has this problem.

How to do this: If you face this problem then first check antena ways then rehot red mark parts and see result.If problem still then change pa.

Nokia c1-01 memory card problem solution

Nokia c1-01 memory card not work solution.If your phones memory card not work then you can repair your phone use this solution.Just following bellow picture.

How to do this : check memory card switching if switch ok but problem still then re-hot red mark memory card ic or replace ic.

Nokia c1-01 mic solution

Now I showing nokia c1-01 mic problem solution.If your nokia c1-01  has mic not work or low sound or bad noise problem.If have problem one of them then you can repair your phones problem using this solution.

How to do this solution: change mic and chek your phone if problem still then check mic related parts and mic ways line.

Nokia c1-01 lcd display ways

Now I showing how to repair nokia c1-01 lcd display problem solution.Many time may be broken lcd line ways when you face this situation then you help this solution.

How to do this : when will this problem of your phone then check all line if you get any fault or broken any line then repair that line.

Nokia c1-01 ringer problem speaker problem solution

Ringer is most important for every mobile phone.Any time may be damage ringer part in any phone.Now I showing how to repair nokia c1-01 ringer problem or speaker problem solution.

How to do this : First check ringer speaker next check this jumper if you get any line broken then make jumper following this solution.

How to master reset Nokia lumia 520

Nokia is the most popular brand of the world.Till now nokia has made many model handset .Maximum phone has been popular.But Nokia windows phone has been more popular.Nokia windows phone have more advance feature so Its may be systemless for wrong operating.When a phone   has systemless then need master reset Now I showing How to master reset Nokia lumia 520 phone.

At first we will know details of nokia lumia 520

Processor	Dual-core 1 GHz
Ram	512mb
Internal memory Memory card support	8Gb 64GB
Sim	Micro sim One sim
Display	IPS LCD capacitive touchscreen, 16M colors 480 x 800 pixels, 4.0 inches (~233 ppi pixel density)
Software platform	Windows Phone 8
Network	850 MHz 900 MHz 1800 MHz 1900 MHz
Battery	1430.0  mAh,3.7v,BL-5J
Camera	5mp

we can Its master reset two ways

One of them:

Turn on the Nokia Lumia 520 then Go to menu: Setting > About > Reset Your Phone next give code then The process of formatting Nokia Lumia 520 will do by it self

Another of them :

Press and Hold the Power Button, do not release until the phone vibrate (if you feel the vibrate in Nokia Lumia 520 then release the Power Button)

Press and Hold the Volume Down Button, do not release until the LCD show the exclamation mark (if you see the exclamation mark in LCD, then release the Volume Down Button)

To continue reset, you have to do the last step bellow

Press Volume Up Button Key and release

Press Volume Down Button Key and release

Press Power Button Key and release

Press Volume Down Button Key and release

The the Nokia Lumia 520 will do the hard reset format

Symphony w20 hard reset

May be lock your symphony w20,Or you set password but you do not know your password then you need master reset your phone now I showing how to hard reset your symphony w20 phone.

How to do this : press  volume & power button hold Together some second then you will see  Recovery Mode then select  Choice Clear Flash.Your phone will restart and solve your problem.

How to solve computer automatic restart

Computer is very necessary  in our daily life.Computer is a most sensitive electronics product so its may be many problem.Now I showing how to repair computer restart problem or how to solve computer restart problem.May be many reason for computer restart.


Problem #1 : If your computer restart when windows screen running

Solution of problem #1: Maximum  time  has  this problem  windows corrupted / Windows damage / windows file missing or effect by virus this problems solution is setup windows and scan update antivirus.

 Problem #2: If your computer restart after some time of turn on.

Solution of problem #2:  This type problem has may be damage cooling or ram Loose so check cooling fan if  necessary change cooling fan and open ram then clean ram with tissue paper or eraser after that replace ram.

How to clean ram

 Problem #3: If your computer has Suddenly restart.

Solution of problem #3: If your computer has Suddenly restart this problem has may be virus or  ram Loose so first open ram then clean ram with tissue paper or eraser after that replace ram.then check your computer if problem still then windows setup.


Problem #4:  If your computer has Suddenly restart or when electricity voltage drop/voltage up /down then restart problem.

Solution of problem #4: Maximum time This problem has for power supply weak so replace power supply.

Nokia c1-01 power button ways jumper

If your nokia c1-01 phone is charging ok but phone not on then you repair your phone using this solution or if you see broken power button line.This is only power button ways just check power button ande make this jumper.

How to do this work: If you face this problem then first open button sticker and clean power button.after that check your phone if problem still then check power button ways if you get broken any line then make jumper following this solution.

Nokia c5-00 charging solution

Nokia c5-00 is most popular phone.Now I share how to repair Nokia c5-00 charging problem.It is very simple solution.view the below picture and work following this picture.

How to do this : If you face nokia c5-00 charging problem.At first check charger or check your phone other charger If problem still then check this red mark parts and charging line ways.

Nokia c5-00 Mic solution

Today I will show how to repair Nokia c5-00 mic ways or mic problem.May be some phone has mic problem If you face this problem then repair using this solution.

How to do this : If your phone has this problem then first change mic if problem still then check this line.

Nokia 110 charging solution

Charging problem is very common problem of mobile phone. May be any phone has this problem so its repairing solution is very important for mobile phone servicing.Now I showing how to repair nokia 110 charging problem.when you plugin a good charger in your phone then no response on your phone.If you have this problem in your phone then just view below picture and work following this .

How to do this : If your phone has this problem then open your phone check charging base next check fuse, diode, and charging line ways if you found any fault then repair that.
